Description:

Green crystals that produced in the same manner as black silicon carbide. It is electric furnace resistance with petroleum coke, quartz, and other materials. It has properties of high hardness, strong cutting capacity, stable chemical properties, and good heat conduction.

Application:

Cutting & Grinding of Solar Silicon Chips, Semiconductor silicon chips & Quartz Chips
Polishing of Crystal & Ferrite
Precision Polishing of Ceramics & Special Steel
Cutting & Free Grinding
Polishing for Bonded Abrasives & Coated Abrasives
Grinding of Glass
Agate
Superb Jewels
Jade-ware

Technical Data:

Chemical Composition

	SiC≥ %	F.C≥ %	Fe2O3≥ %
12#- 90#	99	0.2	0.2
1000#- 180#	98.5	0.3	0.3
220#	98	0.3- 0.6	0.3- 0.6

Physical Properties

It is in the micro shape of hexagonal shape.
Mohs Hardness: 9.2- 9.6
Vickers Hardness: 3000- 3300

	Chemical Index(%)			Physical Index
grains	SiC ≥ %	F.C. ≤ %	Fe2O3 ≤ %	PH value	Bulk Density	Magnetic Material
#240	99.00	0.13	0.13	6-7.5	1.25	0.01
#280	99.00	0.13	0.13	6-7.5	1.23	0.01
#320	99.00	0.12	0.12	6-7.5	1.23	0.01
#360	99.00	0.12	0.12	6-7.5	1.20	0.009
#400	99.00	0.13	0.13	6-7.5	1.20	0.009
#600	99.00	0.13	0.13	6-7.5	1.18	0.009
#800	99.00	0.12	0.12	6-7.5	1.18	0.008
#1000	99.00	0.12	0.12	6-7.5	1.15	0.008
#1200	99.00	0.15	0.13	6-7.5	1.13	0.005
#1500	99.00	0.15	0.13	6-7.5	1.12	0.005
#2000	99.00	0.14	0.15	6-7.5	1.00	0.005
#2500	98.00	0.30	0.30	6-7.5	1.00	0.007
#3000	97.00	0.35	0.30	6-7.5	0.92	0.007
#4000	97.00	0.35	0.30	6-7.5	0.92	0.007
#6000	97.00	0.25	0.30	6-7.5	0.90	0.007

	Chemical Index(%)
grains	SiC ≥ %	F.C. ≤ %	Fe2O3 ≤ %
#240	99.00	0.13	0.13
#280	99.00	0.13	0.13
#320	99.00	0.12	0.12
#360	99.00	0.12	0.12
#400	99.00	0.13	0.13
#600	99.00	0.13	0.13
#800	99.00	0.12	0.12
#1000	99.00	0.12	0.12
#1200	99.00	0.15	0.13
#1500	99.00	0.15	0.13
#2000	99.00	0.14	0.15
#2500	98.00	0.30	0.30
#3000	97.00	0.35	0.30
#4000	97.00	0.35	0.30
#6000	97.00	0.25	0.30

	Physical Index
grains	PH value	Bulk Density	Magnetic Material
#240	6-7.5	1.25	0.01
#280	6-7.5	1.23	0.01
#320	6-7.5	1.23	0.01
#360	6-7.5	1.20	0.009
#400	6-7.5	1.20	0.009
#600	6-7.5	1.18	0.009
#800	6-7.5	1.18	0.008
#1000	6-7.5	1.15	0.008
#1200	6-7.5	1.13	0.005
#1500	6-7.5	1.12	0.005
#2000	6-7.5	1.00	0.005
#2500	6-7.5	1.00	0.007
#3000	6-7.5	0.92	0.007
#4000	6-7.5	0.92	0.007
#6000	6-7.5	0.90	0.007

Granularity Distribution (um):

grains	D0 ＜	D3 ＜	D50	D94 ＞
#240	120.0	100.0	57.0±3.0	40.0
#280	110.0	80.0	48.0±3.0	33.0
#320	93.0	70.0	40.0±2.5	27.0
#400	70.0	53.0	30.0±2.0	20.0
#600	50.0	38.0	20.0±1.5	13.0
#800	30.0	20.0	14.0±1.0	9.0
#1000	25.0	17.5	11.5±1.0	7.0
#1200	20.0	16.5	9.5±1.0	6.0
#1500	18.0	15.0	8.0±0.6	4.8
#2000	16.0	13.0	6.7±0.6	4.0
#2500	15	13.0	5.5±0.5	3.0
#3000	13	11.0	4.0±0.5	2.0
#4000	11	8.0	3.0±0.4	1.3
#6000	8	5.0	2.0±0.4	0.8

Grits Available:

F220, #240 to #6000.
In accordance with the current GB/ FEPA/ JIS sieve standards.
